Operation Table
Electric OT Table Advanced
Model OT11
- ISO 13485:2016Certified manufacturer
- OEM / ODMCustomisation available
- Export-grade packagingFor international shipment
- Global shippingSupplied to 50+ countries
Description
✅ SS-304 | ✅ Surgeons Panel | ✅ Electric (remote operated) | ✅ C Arm Compatible | ✅ Floor Locking | ✅ Zero Positioning
Fully electrically operated table, five sections, radio-translucent table with eccentric pillars and Die compressed base.
Interchangeable head and leg sections (manually)
All positions operated through cable remote.
Electric floor locking. (Optional)
Inbuilt kidney bridge.
Auto leveling (zero function)
We are providing two handsets. The additional fixed control panel provided on the tabletop, which can be used in case of failure of the main handset.
Indication of battery back provided in the handset.
The handset provides dual memory functions which can be set and reset.
Top dimension | L 1900mm x W 522mm |
Height adjustment | 750mm - 1000 mm |
Trendelenburg / Reverse | 30° / 25° |
Lateral Tilt | 20° / 20° |
Kidney elevator | 130mm |
Backrest (up/down) | 60° / 25° |
Leg rest (up/down) | 15° / 90° |
Headrest (up/down) | 20° / 60° |
Power Supply | 24V DC |
Battery Backup | 2-3 hours (optional) |
Mains Voltage | AC 220V ±10% 50Hz |
Patient weight capacity | 200 kgs. |
