Operation Table
Electro Hydraulic OT Table
Model OT13
- ISO 13485:2016Certified manufacturer
- OEM / ODMCustomisation available
- Export-grade packagingFor international shipment
- Global shippingSupplied to 50+ countries
Description
Features:
Tabletop is made with Stainless Steel grade 304 to avoid rust with a canceled pump.
The five-section stainless steel tabletop is equipped with removable, antistatic mattresses.
All the positions are realized by a mechanical driver.
The table is furnished with a hard, robust stainless steel shell which provides the sense of dirt-free & sanitized operations.
Precision-made hydraulic system with single lever action hydraulic life controlled by a foot pedal.
Five sections stainless steel top gives anatomic adaptation to the patient body.
Inbuilt kidney bridge and large perineal cut out for drainage.
Manual Floor locking system.
Technical Data:
Top dimension | L 1900mm x W 520mm |
Height adjustment | 762mm - 1000 mm |
Trendelenburg / Reverse | 30° / 25° |
Lateral Tilt | 20° / 20° |
Kidney elevator | 150mm |
Back rest (up/down) | 80° / 25° |
Leg rest (up/down) | 15° / 90° |
Head rest (up/down) | 20° / 60° |
Patient weight capacity | 200 kgs. |
